Generating Element: Electret Condenser
Polar Pattern:
201R - Unidirectional (Half Cardioid in the plane above boundary)
202R - Omnidirectional (Hemisphere in the plane above boundary)
Frequency Response: 100Hz - 15kHz
Sensitivity: 201R
-36 dBV (16mV) @ 1Pa
Sensitivity: 202R
-30 dBV (32mV) @ 1Pa
Impedance: 150 ohms
Self Noise: Less than 29dB, A weighted
Maximum SPL: 129dB, 1% THD, 1kHz
Powering: P12, P24 and P48 < 3mA
Connector: 3 pin male XLR type
Phasing: Positive pressure on diaphragm generates a positive voltage on pin 2 relative to pin 3.
Finish:
201R, 202R - Durable Black urethane
201RW, 202RW - Durable White urethane
Dimensions: (See drawing)
Net Weight: 65 grams (2.3 oz.)
RF Immunity: Exceeds ENT55103-2, E1, E2, E3 and E4
RoHS Compliant
